Rotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need Dusting

Brand Name : DZ

Model Number : NC-64

Certification : CE ISO

Place of Origin : China(Mainland)

MOQ : 1unit

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 30 units/per month

Delivery Time : 2weeks

Packaging Details : wood

Dimensions (L*W*H) : 4400*3400*2900

Machine Power : 35KW

Rated Voltage : 380V

Max. Diameter of polishing wheel : 600mm

Min. Diameter of polishing wheel : 400mm

X-Axis travel (mm) : 1200

Y-Axis travel (mm) : 1100

Z-Axis travel (mm : 700

U-Axis travel (mm) : ±90°

V-Axis travel (mm) : ±360°

W-Axis travel (mm) : ±360°

Contact Now

High Efficient Rotary Automatic Brass Tube CNC Polishing Machine No Need Dusting

Precision polishing.

- Uniform polishing quality without deformation of the processed parts.

- High production. Simultaneous polishing of two equal parts in each polishing cycle.

- Flexible production. Change of series in the minimum time. The time invested in the preparation of the machine for changing the type of part to polish is about 10 minutes.

- Quick replacement of the fixtures.

- Quick replacement of the polishing mops.

- Cost-reduction in the amount of fixtures.

- Important reduction in mops and polishing compounds consumption.

- Polishing system avoiding excessive temperature of the parts during the working process.

- Quick and easy programming. Interactive Teach System.

- High profitability and amortisation. One single operator can handle several machines by synchronizing the working cycles.

TECHNICAL PARAMETERS

No	Items	Specifications
1	Dimensions (LWH)	300031002900mm
2	Machine Power	17KW
3	Rated Voltage	380V
4	Max. Diameter of polishing wheel	600mm
5	Min. Diameter of polishing wheel	400mm
6	X-Axis travel (mm)	1100
7	Y-Axis travel (mm)	900
8	Z-Axis travel (mm)	700
9	U-Axis travel (mm)	±60°
10	V-Axis travel (mm)	±360°
11	W-Axis travel (mm)	±360°
12	Max.speed X axis	20m/min
13	Max.speed Y axis	20m/min
14	Max.speed Z axis	20m/min
15	Max.speed U axis	30°/sec.
16	Max.speed V axis	30°/sec.
17	Max.speed W axis	30°/sec.

Rotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need Dusting

Product categories

Rotary Automatic Brass Tube CNC Polishing Machine High Efficient No Need Dusting

Company Profile

Certifications

FAQ

Q: could you please arrange the installation and commissioning ?
A: Yes , we could and the buyer pay the charge

Q: could you arrange the production education?
A: Yes , we could and the buyer pay the charge

Q:How long the guarantee?
A: one year and charge for repair the whole life.

Q: How about the lead time and delivery time of my order?
A: Large cargo 15-25 working days, depending on the quantity, and delivered according to the agreed time.
